Volumetric sensor for viscous raw materials

Puuviljad lähevad sisendpunkri kaudu leotamisfaasi. Sealt lift poole puu all teisese selgevee pihustid. Lihtne puhastada, massiivse polüpropüleen/atsetaali moodulliftiga, astmeliselt reguleeritav kiirus mõlemas suunas. Paigaldatud 2ea-le. pöörlev, 2ea. lukustatavad rattad. Vibratsioonivastased jalad. Nõuab minimaalset hooldust.Tehnilised andmed:- Jõudlus: 3000 kg/h- Elektrivajadus: 4,8 kW, 400 V, 16 A- Materjal: WNr. 1.4301, AISI 304 roostevaba terasMõõdud:Pikkus: 4258 mmLaius: 1231 mmKõrgus: 2256 mm- Väljundkõrgus: 1370 mm- Kaal: 420 kg-Vanni veemaht: 800 L- Pesuveevarustus: (100-200L/h olenevalt seadistusest) - Veeühendus: 1/2“ kiirühendus- IP65 sertifikaadiga elektroonika- Massiivse purustusvasaraga veski (saadaval peedi ja küdoonia jaoks)- Veskist saab kõrvale pöörata, nii et sel juhul kasutatakse masinat luuviljaliste töötlemiseks.- Müra emissioon: 60-70 dB- 4 tk tugevat vastassuunas pöörlevat harja intensiivseks puhastamiseks- Pöörlev laba, mis lükkab puuvilju lifti pooleSaadaolevad valikud:- Muudetava läbimõõduga sõel: meski tekstuuri muutmiseks- Stop ‘n’ Go süsteem: membraaniandur, mis võimaldab puuviljapesul/veskil ja rihmpressil koos töötada- Doseerimismoodul: lõpplülitiga lükanduks, mis võimaldab doseerida veskist ohutult pakipressi.

Fruit Washing and Crushing Device. The fruits go to the input hopper, then after soaking move via elevator towards the secondary clear water spray system. Easy to clean, with massive polypropylene/acetal modular elevator, steplessly adjustable speed in both ways, with 2 rotating, 2 fixed wheels or vibration-free feet. Requires minimal maintenance. Technical details: Performance: 1500-2000 kg/h. Electric demands: 4 kW, 400 V, 16 A. Material: Wnr. 1.4301, AISI 304 stainless steel. Weight: 275 kg. Tub water capacity: 280 L. Washing water supply: 100-200 L/h (depending on the setting). Water connection: ¾" quick connector. IP65 certified electronics. Grinder with a massive crushing hammer (available for beetroot and quince). The grinder can be by-passed and turned, this way the machine is capable of processing stone-fruits. Noise emission: 60-70 dB. 4 pcs of strong, counter-rotating brushes for intense cleaning. Requires minimal maintenance. Adjustable belt speed. Options: Changeable diameter sieve: for changing the texture of the mash. Stop 'n' Go system: membrane sensor that allows the fruit washer/grinder and the belt press to work together. Dosing module: sliding door with end-switch that allows safe dosing from the grinder to the pack press. The principle of the device is to clean and crush fruits before juice pressing, ensuring a cleaner and higher quality end product. The device is designed for professional use in the food industry and juice production.

Stainless fruit and vegetable washing and crushing device with auger lifting device. Immediately after cleaning, the product is transported to the crusher by means of an auger. Pre-cleaning of products using water pressure valves and pre-cleaning brushes. Material: stainless (1.4301); Crusher productivity: 2000kg/h. Manufacturer: Maurer Additional price: belt baler start/stop automation, bale baler dispenser.

After rinsing the fruits in the container, the raw materials are washed with clean water using sprayers and forwarded to the crusher. The device enables raw material rinsing/hand washing, lifting transport and crushing. Features: device moving on wheels, easy to clean, massive food-grade plastic modular dingha, adjustable speed stepwise in both directions, 2 pcs rotating, 2 pcs fixed wheels. Additional equipment: Sieves with removable diameter; dosing module: sliding gate with buffer hopper and limit switch, which enables safe grinding of the baler. Specifications: Performance up to: 1500 kg / h, power consumption: 3 kW, 400 V, 16 A, three-phase; Material: WNr. 1.4301, AISI 304 stainless steel; Dimensions: 710x3200x2120 mm; Output height: 1280mm; Weight: 200 kg; Bath water volume: 120 L / change; Washing water supply: (depending on the setting 20-100L / h); Water connection: 3/4 "quick connection; IP65 certified electronics; crusher with massive hammer crusher (available for beet and quince). Noise emission 60-70 dB.

Crusher sieve with 15mm openings.
