VERTICAL VOLUMETRIC FILLER FOR DOSES FROM 100 UP TO 2000 ml NO RETURN VALVE AND NOZZLE WITH GRIDS

Volumetric cylinder dispenser. Doses 250-5000ml..

Volumetric cylinder dispenser. Doses 250-5000ml..

Ideal for bottling wine, juice (up to +80C), beer, milk, syrup (+80C) or cooking oil. Device max. bottling capacity/viscosity is the viscosity of cooking oil. Suitable bottles opening 16-28mm and height 250-330mm. Productivity: wines - up to 250 bottles/hour; gaseous liquids - up to 200 bottles/hour; edible oil - 150 bottles/hour. The set includes additional equipment for bottling wine and juice, which can withstand heat up to +85 C. Additional equipment at an additional cost: bottling of milk and gaseous liquids, filling of large bottles, etc. ACCESSORIES (at extra cost): stainless durable bottle filling nozzle / filtering unit / Kit Kristal kit - for bottling small bottles (bottle mouth min. 12mm) / Kit JAR kit - for bottling jars (jars with a mouth of 33-120mm) / Kit Mignon kit - for bottling small bottles (bottle mouth . 7.5mm) / Set milk kit - for bottling bottles with a large neck like a.la milk bottles (bottle mouth 45-65mm) / Set oil kit - set for bottling oil / Set tomatoe kit - an attachment for bottling tomato juice with a seed filter. In the set "Frutta kit" - standard e.g. for bottling wine or juice (withstands +80C heat)..

Back pressure isobaric small bottler for hobby use. Productivity 80-90pdl/h. Made in Sweden! Dimensions of suitable bottles: height 175-310cm and bottle mouth 26mm. Extras (indicate immediately when ordering): Swing-top bottle bottling nozzle +25EUR Using the device: 1. Connect the bottler to the CO2 and bottle of the liquid to be bottled 2. Place the bottle under the device 3. Fill the bottle with CO2 by pressing the black "+" button 4. Press to the pressure release "-" button 5. Fill the bottle with CO2 by pressing the black "+" button 6. Points no. 3 and 4 should be repeated for min. 2x to ensure sufficient CO2 concentration in the bottle, but lastly, always press the "+" button before bottling 7. Open the liquid supply valve and close the container when it is full..

Ideal for bottling wine, juice (up to +80C), beer, milk, syrup (+80C) or cooking oil. Suitable bottles opening 16-28mm and height 250-330mm. Productivity: wines - up to 250 bottles/hour; gaseous liquids - up to 200 bottles/hour; edible oil - 150 bottles/hour. Accessories for bottling carbonated drinks included in the set. Additional equipment at an additional cost: bottling of milk and gaseous liquids, filling of large bottles, etc. ACCESSORIES (at extra cost): stainless durable bottle filling nozzle / filtering unit / Kit Kristal kit - for bottling small bottles (bottle mouth min. 12mm) / Kit JAR kit - for bottling jars (jars with a mouth of 33-120mm) / Kit Mignon kit - for bottling small bottles (bottle mouth . 7.5mm) / Milk kit set - for bottling bottles with a large neck like a.la milk bottles (bottle mouth 45-65mm) / Oil kit set - set for bottling oil / Tomatoe kit set - tomato juice bottling attachment with seed filter In the "Frutta kit" set - standard e.g. for bottling wine or juice (withstands heat of +80C).

DANA API MATIC 1000 reguleeritava kõrgusega lauastatiiviga on praktiline lahendus väiksemateks tootmisvajadusteks. See pakub samu suurepäraseid funktsioone nagu suuremad mudelid, kuid väiksema täitmismahuga. Integreeritud vabastuslüliti tagab sujuva täitmisprotsessi, võimaldades masinal saavutada oma täieliku potentsiaali. Statiiv mahutab konteinereid kõrgusega 3,5 cm kuni 20 cm. Masin töötab täpselt ja seda on lihtne reguleerida erinevate vedelike ja täitemahtude jaoks. Kõik vedelikuga kokkupuutuvad osad on valmistatud toidukvaliteediga plastist või roostevabast terasest, tagades lihtsa lahtivõtmise ja puhastamise. Seade on mõeldud vedelike täpseks doseerimiseks ja villimiseks erinevate suurustega konteineritesse ning arvutijuhitav hammasrataspump tagab täpse ja ühtlase täitmise. Masina võimsus on 230W ning toide 90-264VAC 50/60Hz. Seadme mõõtmed on P40 x L32 x K41 cm ja kaal 10,5 kg. Täitmistäpsus on +/- 2g ning pumba võimsus 200 l/h. Müratase jääb alla 70 dB(A). Vedeliku maksimaalne temperatuur võib olla kuni 60°C. Masin võimaldab salvestada üle 20 erineva programmi ning sobib konteineritele kõrgusega 3,5 kuni 20 cm. Tegu on arvutijuhitava hammasrataspumbaga, millel on 1½" BS voolikuühendus pumba mõlemal küljel.
