TWO HEADS FILLING AND CAPPING MONOBLOCK

Moboblokk device for bottling light carbonated drinks. Automatic bottling device with 8 nozzles on a rotating base. Automatic capper with pre-feed vibration for cap DN26mm, bottle pick-up line with collection. The bottling process is not isobaric..

Compact stainless steel mobo block from an Italian manufacturer. The standard device bottles and caps bottles in the size of e.g. with a diameter of 75mm (75cl). Caps D22-28mm with a height of up to 50mm. productivity up to 800pdl/h (75cl). The device is also suitable for bottling and capping oil. Additional equipment: conveyor belts, vacuum (accelerates productivity/bottling process)..

Compact stainless steel mobo block from an Italian manufacturer. The standard device fills and caps bottles and can be configured for bottles with a height of up to 375 mm and different diameters. Productivity up to 500pdl/h The device is also suitable for bottling and capping oil. Additional equipment: conveyor belts, vacuum (to accelerate the bottling process up to 800 pdl/h)..

Compact stainless steel mobo block from an Italian manufacturer. A standard automatic device that bottles isobarically, caps and ties the wire to the cap. Suitable bottles in the size of e.g. with a diameter of 75mm (75cl). Productivity up to 350-450pdl/h (no bubble 600-800pdl/h, light bubble 200-400pdl/h, sparkling wine 180-300pdl/h). electricity 1.5kw, dimensions 910x1700x2050mm, approx. 580 kg. Additional equipment: different bottle formats, cap and wire feeders, labeler..

Semi-automatic monobloc for filling and sealing tare (cans, bottles). Cap and bottle filling and closing device for screw caps. The semi-automatic air-operated machine is suitable for bottling liquid or semi-liquid products into cans or bottles. All parts that come into contact with the product are made of AISI 316L stainless steel and complete with seals that comply with food standards. The corkscrew has an adjustable torque and a pneumatic motor. Productivity up to 400 cans/h for 350ml cans. Volume cylinders are available for bottling tare in the following sizes: 5 to 250 ml; 5 to 380 ml; 20 to 680 ml; 50 to 1500 ml This device can fill viscous products containing soft solid particles or fibers and is also suitable for hot filling (95°C). Technical characteristics: The main frame of the machine is made of stainless steel AISI 304; All the supports and the shaft of the machine, which may come into contact with the raw material, are made of stainless steel AISI 304; manual individual arrangement of the jar; Volumetric filling module consisting of: 1 part AISI 316 L stainless steel; 1 set with gaskets; 1 three-way rotary valve; 1 pneumatic two-way shut-off valve without shut-off nozzle; Food grade flexible hose; A single-ended capper consisting of: 1 pneumatic motor; 1 stainless steel nozzle of one size; Manual height adjustment of the machine. Air consumption ~ 250 Nl / min compressed air 2 - 6 bar.

Can filling device and capper for cans of different sizes: diameter 63-66 and different heights - 33cl...50cl. Productivity up to 600 cans/h. Electricity 0.5kw/220V/24V, compressed air supply required 6bar, working room temperature +2C...+40C. On a stainless steel frame. Bottled beverage temperature 0...+2C to reduce foam, carbonation level 4.6...4.6g/l, bottling from an isobaric container with measurement control. Mechanical sealing of cans..

Can filling device and capper for cans of different sizes (bottling open to the air): diameter 63-66 and different heights - 33cl...50cl. Productivity up to 1200 cans/h. Electricity 220V/24V, compressed air supply required 6bar, working room temperature +2C...+40C. On a stainless steel frame. Bottled beverage temperature 0...+2C to reduce foam, carbonation level 4.5...5.5g/l, bottling from an isobaric container with precise pressure control (pressure fluctuation in the container causes incorrect bottling results in cans). Electronic control panel, dosing of CO2 into the can before bottling, after bottling, mechanical lid closer, automatic tare weight control after bottling, technical maintenance possible via internet cable. Dimensions: length 2500mm, height 3010mm, width 950mm. The device includes: the described device and a round pick-up table. Made in Italy..

Automatic isobaric bottling and capping device suitable for bottling various carbonated drinks up to 5bar. productivity 600/850pdl/h depending on the nature of the drink and the size of the bottle. Dimensions of bottles to be used min. diameter 55mm and height 110mm and max. diam 110mm and height 350mm. Power consumption 400V/3kw, compressed air consumption 120l/min 7bar, tri-clamp connections. Crown capping 26mm or 29mm - with automatic cap vibrating container and pre-feed. The operation of the device can be controlled using the control center..

Semi-automatic bottle dispenser-bottler made in Italy. Suitable for bottling viscous liquids such as yogurt, jam, honey, processed cheese; pastas; sauces; creams, etc. room temperature or hot. Suitable bottles up to 1000ml (testing sample bottles at the factory). Stopper for bottles with screw caps. Productivity up to 600 bottles/hour. The bottling and capping operations take place automatically - the operator must manually place the cap on the bottle between the two operations. Technical data: stainless steel frame and adjustable legs; moving bottle feeding belt 2m with bottle end pick-up table; pneumatic stopper dispenser - stops bottling when there is no bottle; volumetric dosing pump; stainless steel dispenser with deflon seals; micrometric screw for dosing adjustment 40 - 1000cc; the dispenser has a drip-proof tip; the corkscrew works with pneumatic air pressure, at low speeds and with adjustable power. The printer is not included in the price..

Italian high-quality semi-automatic tare wash, isobaric bottler with 4-bottle nozzle and crocker for crown caps. On order, a device with a 2-bottle nozzle or a 6-bottle nozzle and for crown caps or screw caps. Suitable for bottling various gaseous liquids such as beer, cider, sparkling wine, carbonated water, etc. Maximum bottling pressure 5bar. Foam reducing nozzles; Power consumption 0.37kw/220V; Compressed air consumption 120l/min/6bar, 24V; Dimensions h1.92m x 0.8m x 0.40m; Suitable bottles max. height 350mm and max. diameter 120mm; Bottling process - visible in the video below. Extras: Automatic bottling process; Pneumatic pump for pumping liquids into the bottle; Introduction of CO2 into the tare before bottling - the result is foam-free bottling; Automatic transparent protective door; Automatic cycle; Washing liquid recycling; Corker's fiberizing container - automatic shaking of corks on the device's rail; The corker sprays water into the bottle - releasing oxygen with a little foam - higher quality result; Integrated pressure sprayer for cleaning the internal tank; Set of gaskets for 1" connection valve; Additional pipes, to ensure different bottling levels in bottles; Bottle models, for cleaning valves; Return valve..

Moboblokk device for bottling light carbonated drinks. Automatic bottling device with 8 nozzles on a rotating base. Automatic capper with pre-feed vibration for cap DN26mm, bottle pick-up line with collection. The bottling process is not isobaric..

The multiblock includes tare rinsing, isobaric bottling with an accuracy of +/-2mm, crown capping and bottle feeding and picking tables. All this so that the device can be operated by 1 operator. Technical data: - Fillable product - Carbonated e.g. beer - Bottle type - glass - Closure type - crown cap Ø 26 mm - Filling valves 6 - Limiting head 1 - Flushing system - with water - single stage with 6 heads - Filling system - electro-pneumatic isobaric filling valves - Filling temperatures 0-2C° - Device rotation - clockwise - Multiblock dimensions 2065x1444x2100(H)mm, total required surface 6000x2800mm - Productivity up to 1200pdl/h 330 ml Extras: liquid sterile filtration system, additional conveyors for 1-operator management, details for handling bottles of different sizes in the device, material in contact with liquid AISI316, creamer details for 29mm crown cap, CO2'e dosing after bottling and before capping, spray washing bottles after capping to remove foam residues, feed pump for the bottling line, modem to manage the device via the Internet, installation of 2 labels for the labeler or, in addition, installation of a neck tag..

The fully automatic isobaric triblock in the Revolving version, with a crown capping machine and a canning machine integrated on the same rotating column. This advanced configuration optimizes energy consumption and significantly reduces the footprint, ensuring maximum operational efficiency in small spaces.
