rib-sieve 15mm

The fruits go via the input hopper to the soaking stage. From there the elevator towards the fruit under the secondary clearwater sprays. Easy to clean, with massive polypropylene/acetal modular elevator, steplessly adjustable speed in both ways, Mounted on 2ea. swivel, 2ea. lockable wheels or on adjustable Anti-vibration feet. Requires minimal maintenance.Specifications:  - Performance: 2000 kg/h , - Electric demands: 3 kW, 400 V, 16 A,  - Material: WNr. 1.4301, AISI 304 stainless steelDimensions:  Length:   4200 mm, Width:     1250 mm, Height:    2222 mm, - Output height: 1270 mm , - Weight: 240 kg , - Tub water capacity: 280 L/shift , - Washing water supply: (20-100L/h depends on the setting) , - Water connection: 3/4“ quick connector, - IP65 certified electronics , - Grinder with a massive crushing hammer (also suitable for beetroot and quince) , - Noise emission: 60-70 dB  Available options: Changeable diameter sieve: for changing the texture of the mashStop ‘n’ Go system: membrane sensor, which synchronizes the fruit washer/grinder and the belt press to work togetherDosing module: a manual sliding gate with an end-switch, that allows the dosing from the grinder safely to the pack press.

The fruits go via the input hopper to the soaking stage. From there elevator towards the fruit under the secondary clearwater sprays. Easy to clean, with massive polypropylene/acetal modular elevator, steplessly adjustable speed in both ways. Mounted on 2ea. swivel, 2ea. lockable wheels or on adjustable Anti-vibration feet. Requires minimal maintenance.Specifications: - Performance: 2000 kg/h - Electric demands: 4 kW, 400 V, 16 A- Material: WNr. 1.4301, AISI 304 stainless steel  Dimensions: Length:  3325 mm, Width:     953 mm, Height:  2158 mm - Output height: 1400 mm,  - Weight: 290 kg , - Tub water capacity: 280 L/shift , - Washing water supply: (100-200 L/h depending on the setting) , - Water connection: 3/4“ quick connector,  - IP65 certified electronics , - Grinder with a massive crushing hammer (also suitable for beetroot and quince),  - The grinder can be bypassed by swinging to the side so this way the machine is used for processing stone fruits. - Noise emission: 60-70 dB, - 4 pcs of strong, counter-rotating brushes for the intense cleaningAvailable options: - Changeable diameter sieve: for changing the texture of the mash - Stop ‘n’ Go system: membrane sensor, that allows the fruit washer/grinder and the belt press work together - Dosing module: sliding door with end-switch, that allows the dosing from the grinder safely to the pack press.

Additional equipment of the crusher M100 - stainless sieve with 3 mm holes, which is suitable for crushing berries..

Stainless fruit and vegetable washing and crushing device with auger lifting device. Immediately after cleaning, the product is transported to the crusher by means of an auger. Pre-cleaning of products using water pressure valves and pre-cleaning brushes. Material: stainless (1.4301); Crusher productivity: 2000kg/h. Manufacturer: Maurer Additional price: belt baler start/stop automation, bale baler dispenser.

Additional equipment of the crusher M100 - a stainless screen with round holes..
