Pasteurizer inox 50L

High-quality instant pasteur made in Slovenia. Technical data: Productivity 60-90l/h, Dimensions height 1800mm, Ø400, Pasteurization 75-85 C, Power 6kw/380V, Automation: adjustable digital thermostat for determining heating water heat and manual for visual control.

Stainless pasteurizer, to which you can purchase either a storage bag bottler with a productivity of up to 180l/h (+20C to +80C) or a bottle bottler - one of the selected bottlers is included in the price of the device. Electric power 18kw/400V/32A. Dimensions: 750x2050x1170 mm.

Pasteurizers are equipped with spiral heat exchangers and a hot water circulation pump. The juice tube is located inside the hot water tube with a larger diameter - hot water and the juice to be pasteurized move in opposite directions to each other, ensuring even heating of the juice. The power of the pasteurizer is stepwise adjustable according to the number of working heaters. The thermostat ensures the maintenance of the hot water temperature set by the user, which should be 4-5 degrees warmer than the temperature of the juice coming out. In the case of EHA18, EHA27 and EHA45 models, setting the juice temperature is by changing the flow rate using a manually adjustable valve, an external pump is required to supply the raw juice. EHA18E, EHA27E and EHA45E are equipped with a juice pump and the ability to automatically adjust the temperature of the juice. Pasteurizer EHA-40 productivity up to 400l/h / +80°C and oil burner capacity. 48kw. Size 1000x1000x1200mm, weight 280kg. The set includes a juice pump and a fully automatic control center..

Pasteurizer bath & the boiler is suitable for heat treatment of raw materials in packaging or without packaging (e.g. fruit and vegetable producers). Using the crane lifting device, it is easy to remove the product from the tub and place it on the work surface next to it. Bath size: 400l, power 24kw/32A/400V, heat exchanger (soft water), IP65, weight 265kg. Maintains the specified temperature (1-thermometer). Overall dimensions 2510x970x2050mm, internal lifting baskets dimensions 6pcs 540x270x390mm, water baths 2pcs dimensions 1pc 900x600xH460mm, lifting device. Material: 100% stainless steel AISI304. The dimensions of the baskets, tub and the whole set can be adjusted during production! The price is given for the standard model. Extras: side tables, automatic water level control, extra baskets..

Stainless steel cooling pipe 9.5mm and sphere diameter 26.5cm, total height 55cm and spiral height 19cm. Warranty 3 years. Connection fittings Gardena watering hose fittings. It is possible to cool e.g. 50l approx. +100C feed liquid for 20 min. to +20C if the coolant is +13C..

Pasteurizers are equipped with spiral heat exchangers and a hot water circulation pump. The juice tube is located inside a larger diameter hot water tube - hot water and juice to be pasteurized move in opposite directions to each other, ensuring uniform heating of the juice. The power of the pasteurizer is stepwise adjustable according to the number of working heaters. The thermostat ensures the maintenance of the hot water temperature set by the user, which should be 4-5 degrees warmer than the temperature of the juice coming out. In the case of EHA18, EHA27 and EHA45 models, setting the juice temperature is by changing the flow rate using a manually adjustable valve, an external pump is required to feed the raw juice. EHA18E, EHA27E and EHA45E are equipped with a juice pump and the ability to automatically adjust the temperature of the juice. Pasteurizer EHA-45E productivity up to 450l/h / +80°C and power is 45kw 400V. Warm-up time approx. 8 min. Size 750x850x1400mm, weight 230kg. Setting the temperature of the juice by changing the flow rate using a manually adjustable valve, an external pump is required to supply the raw juice..
