Monoblock filling - jar capping 600pc/h

Moboblokk device for bottling light carbonated drinks. Automatic bottling device with 8 nozzles on a rotating base. Automatic capper with pre-feed vibration for cap DN26mm, bottle pick-up line with collection. The bottling process is not isobaric..

Compact stainless steel mobo block from an Italian manufacturer. The standard device bottles and caps bottles in the size of e.g. with a diameter of 75mm (75cl). Caps D22-28mm with a height of up to 50mm. productivity up to 800pdl/h (75cl). The device is also suitable for bottling and capping oil. Additional equipment: conveyor belts, vacuum (accelerates productivity/bottling process)..

Compact stainless steel mobo block from an Italian manufacturer. The standard device fills and caps bottles and can be configured for bottles with a height of up to 375 mm and different diameters. Productivity up to 500pdl/h The device is also suitable for bottling and capping oil. Additional equipment: conveyor belts, vacuum (to accelerate the bottling process up to 800 pdl/h)..

Compact stainless steel mobo block from an Italian manufacturer. A standard automatic device that bottles isobarically, caps and ties the wire to the cap. Suitable bottles in the size of e.g. with a diameter of 75mm (75cl). Productivity up to 350-450pdl/h (no bubble 600-800pdl/h, light bubble 200-400pdl/h, sparkling wine 180-300pdl/h). electricity 1.5kw, dimensions 910x1700x2050mm, approx. 580 kg. Additional equipment: different bottle formats, cap and wire feeders, labeler..

Semi-automatic monobloc for filling and sealing tare (cans, bottles). Cap and bottle filling and closing device for screw caps. The semi-automatic air-operated machine is suitable for bottling liquid or semi-liquid products into cans or bottles. All parts that come into contact with the product are made of AISI 316L stainless steel and complete with seals that comply with food standards. The corkscrew has an adjustable torque and a pneumatic motor. Productivity up to 400 cans/h for 350ml cans. Volume cylinders are available for bottling tare in the following sizes: 5 to 250 ml; 5 to 380 ml; 20 to 680 ml; 50 to 1500 ml This device can fill viscous products containing soft solid particles or fibers and is also suitable for hot filling (95°C). Technical characteristics: The main frame of the machine is made of stainless steel AISI 304; All the supports and the shaft of the machine, which may come into contact with the raw material, are made of stainless steel AISI 304; manual individual arrangement of the jar; Volumetric filling module consisting of: 1 part AISI 316 L stainless steel; 1 set with gaskets; 1 three-way rotary valve; 1 pneumatic two-way shut-off valve without shut-off nozzle; Food grade flexible hose; A single-ended capper consisting of: 1 pneumatic motor; 1 stainless steel nozzle of one size; Manual height adjustment of the machine. Air consumption ~ 250 Nl / min compressed air 2 - 6 bar.

Stainless steel (AISI 304) hot raw material mixing, dosing and capping block with a productivity of up to 1500 units/h. Technical data: PLC: Siemens / Pneumatic components: Camozzi / Consumption: 400V - 50Hz, compressed air 6 bar / Power: 8Kw / Air supply: 900 Nl / min / Dimensions: 3.000x2500mm / Weight: ± 900 kg...

Can filling device and capper for cans of different sizes (bottling open to the air): diameter 63-66 and different heights - 33cl...50cl. Productivity up to 1200 cans/h. Electricity 220V/24V, compressed air supply required 6bar, working room temperature +2C...+40C. On a stainless steel frame. Bottled beverage temperature 0...+2C to reduce foam, carbonation level 4.5...5.5g/l, bottling from an isobaric container with precise pressure control (pressure fluctuation in the container causes incorrect bottling results in cans). Electronic control panel, dosing of CO2 into the can before bottling, after bottling, mechanical lid closer, automatic tare weight control after bottling, technical maintenance possible via internet cable. Dimensions: length 2500mm, height 3010mm, width 950mm. The device includes: the described device and a round pick-up table. Made in Italy..

Automatic isobaric bottling and capping device suitable for bottling various carbonated drinks up to 5bar. productivity 600/850pdl/h depending on the nature of the drink and the size of the bottle. Dimensions of bottles to be used min. diameter 55mm and height 110mm and max. diam 110mm and height 350mm. Power consumption 400V/3kw, compressed air consumption 120l/min 7bar, tri-clamp connections. Crown capping 26mm or 29mm - with automatic cap vibrating container and pre-feed. The operation of the device can be controlled using the control center..

Cannular Täisautomaatne Purgistusliin - Üherealine. Purgistamine on parim viis teie õlle pakendamiseks, pakkudes mitmeid eeliseid pudelite ees. Purgid on keskkonnasõbralikumad kui klaas. Tänu madalamale lahustunud hapniku tasemele (DO) püsib teie toode kauem värske ja säilib paremini. Täielik hermeetiline sulgemine takistab hapniku sisenemist. Purgid on ideaalsed välitingimustes tarbimiseks või üritusteks, kus klaas ei ole soovitatav. Need on täielikult valguskindlad ja atraktiivse etiketiga paistab teie toode turul silma. Cannular Täisautomaatne Üherealine Purgistusliin on loomulik valik lihtsasti käsitsetava kommertslahendusena pruulikodadele ja muude karboniseeritud jookide tootjatele. See on taskukohane lahendus, mis on spetsiaalselt suunatud mikropruulikodadele. See purgistusliin sobib väikese kuni keskmise suurusega pruulikojale, mis toodab partiisid mahuga 1000-5000 liitrit. Seade töötab ühefaasilise 230V elektrivõrguga. Standardvarustuses on B64 padrun, mis sobib 202 purgi kehadele. Tänu kompaktsele suurusele (standardse kaubaaluse suurune) on seadet lihtne paigutada. Karastatud padrun (Cr12MoV, titaankattega, kõvadus 58-62 dH) tagab pika kasutusea. Masin on lihtsasti puhastatav tänu voolikuga pestatavatele pindadele. Tootlikkus on kuni 15 purki minutis, põhinedes tööstuse standardil ühe täitepea kohta (330 ml purgid, madal karboniseeritus, madal temperatuur). Masin vajab vaid üht operaatorit ning suudab hoida lahustunud hapniku taset alla 40 ppb. Cannular täisautomaatne purgistusliin töötab põhimõttel, kus tühjad purgid liiguvad automaatselt täitmispositsiooni, täidetakse tootega, suletakse hermeetiliselt ja väljutatakse seejärel pakendamiseks. Kogu protsess on automatiseeritud, mis vähendab inimvea võimalust ja tagab järjepideva kvaliteedi.

Stainless gravity bottling device for bottles with temperature sensor. Productivity: 2 bottling nozzles 340l/h; 4-670 l/h. Bottling nozzles 15mm; A volume sensor integrated in the container, which allows connection to the pasteurizer and pump for automatic filling of the container. Pipes made of heat-resistant plastic..

Back pressure isobaric small bottler for hobby use. Productivity 80-90pdl/h. Made in Sweden! Dimensions of suitable bottles: height 175-310cm and bottle mouth 26mm. Extras (indicate immediately when ordering): Swing-top bottle bottling nozzle +25EUR Using the device: 1. Connect the bottler to the CO2 and bottle of the liquid to be bottled 2. Place the bottle under the device 3. Fill the bottle with CO2 by pressing the black "+" button 4. Press to the pressure release "-" button 5. Fill the bottle with CO2 by pressing the black "+" button 6. Points no. 3 and 4 should be repeated for min. 2x to ensure sufficient CO2 concentration in the bottle, but lastly, always press the "+" button before bottling 7. Open the liquid supply valve and close the container when it is full..

Stainless gravity cold bottling device for 6 bottles. Made in Italy. Bottling nozzles 15mm; electronic volume sensor to control the pump, setting the amount of liquid on the bottle tips; stainless drain valve; device movable, i.e. on wheels with brakes, productivity 980l/h; Size: 860x1800x900 mm; Weight 80 kg. Additional equipment: pump, foam reduction valve (e.g. when bottling beer), bottling nozzles 17mm, filter, CO2 dosing into an empty bottle..

High-quality and semi-automatic bottling device for bottling juice storage bags and bottles. Fully automatic bottling cycle (bags): vacuum->filling->closing->+CO2. Productivity; 3L - 350 pcs/h; 5L-300pcs/h; 10L-180pcs/h; 20L-130pcs/h; Accuracy +/- 5cl. Power: 1.1kw + 1.5kw (220V or 380V). Air pressure: 6bar; CO2 pressure: 1bar; Dimensions: 60x82x150cm; Weight: 70kg. Made in Italy. Included: PLC panel control with touch screen and multilingual program / Electromagnetic gauge-sensor (Burkert type), for cold liquid (such as wine / water) / vacuum system and nitrogen system / automatic piston to block the filling head / pump HP 1.5 with bypass capacity 4500lt /h / double start switch / bottler, setting range from 1l to 30 liters / semi-automatic handle for opening/closing the filling head with adjustable height / selection of open and close taps. VITOP standard (other on request) / stainless steel work table with 4 wheels / device cleaning fittings (CIP) / Automatic cleaning program / non-return valve in the pump system / connecting pipes and fittings (triclamp 1.5"). On the other side of the device, bottle bottling nozzles 4pcs with adjustable level. Extras : stainless control panel, CO2 pressure reduction valve, oil bottling accessory, bottling speed control, filters, pouch-up bag bottling, bag->box mounting accessory..
