Liquid meter (Fill-O-Meter) with EU plug, automatic
.png){kind=small}
Professionals recommend - producers prefer!
EAN: 20000000541965
Brand:
Unit: tk
Stock qty: On special order
Leveranstid inom Estland för lagervaror ca 3-5 arbetsdagar. OBS! På grund av den snabba prisökningen kan priser för icke-lagervaror ändras utan föregående meddelande! Standardpriser med 22% moms.
Liquid Meter (Fill-O-Meter) with EU plug, automatic
An essential device for every homebrewer. Don't waste time standing by the hose, set the required amount and focus on other brewing tasks. That's the KegLand way!
Perfect gift for any homebrewer, regardless of skill level, because we all need water for brewing beer.
The liquid meter accurately measures water quantity and automatically shuts off when the desired amount is reached. Unlike regular tap timers that simply measure time, the Fill-O-Meter measures water volume and automatically shuts off when the preset water amount has been dispensed.
Features:
- Displays real-time flow rate and volume (liters/min or gallons/min)
- Includes mains power supply (never change batteries again)
- Accurately measures and controls volume at flow rates 1-30 l/min
- Prevents container overflow
- Splash-proof housing
- Perfect for filling pools, tanks, brewing equipment, distilling equipment, liquid mixing and many other applications
- Integrated flow meter and solenoid valve
- Illuminated display for evening use
- Integrated audio signal
- Simple 1/2" BSP inlet and outlet ports
- Option to measure garden water usage
WARNING: DO NOT overtighten inlet and outlet ports.
Important notes:
- DO NOT allow liquid to flow in the wrong direction, it will damage the device.
- DO NOT overtighten fittings into 1/2" ports.
- DO NOT exceed temperature above 80°C in the device.
Technical specifications:
- Power input: 100-240VAC (50/60Hz)
- Power output: 24V DC, 1.5A
- Flow range: 1-30 l per minute
- Temperature range: 0°C to 40°C at mains pressure (12.4 bar) or up to 80°C at 4.1 bar
- LCD: 3-inch backlit display
- Housing material: ABS
- Inlet/outlet thread: G1/2"
- Pressure range: 0-12 bar (0-180 psi)
- Accuracy: +/- 5%
Note: Accuracy can be improved with stable flow. Repeated start/stop or fluctuations in water supply may negatively affect accuracy.
SAFETY FEATURE:
If power is lost for any reason, the Fill-O-Meter will shut off flow.
Operating principle:
The liquid meter works on a flow-through principle where the device measures flowing liquid and automatically stops flow when the preset amount is reached. Enter the desired liquid amount, turn on the tap, and the device does the rest.
