Labeler manual for jars, Swienty

High-quality table-top labeller made in Italy for sticking the label on the top of the box/package. Consists of: labeler LABELX JR 140-T + pneumatic attachment PN-01 + product setting frames LBS-22. Suitable labels are 15-140mm wide and 10-350mm long. Roll of labels max. diameter 300mm. Productivity up to 30m/min. Label accuracy +/- 1mm..

High quality labeler made in Italy that sticks the label to the side of cups/containers. Set: labeler LABELX JR 140-EW + label adjuster REG-04 + belt conveyor NTC-03 (150x1500mm) + refactor start sensor FC-03 + product rotary switch WRX-04 + rotary switch setting WRX-106 + stainless steel frame of the labeler BSX-05 + pneumatic vacuum pad PN-36 + tilt regulator REG-08 + stainless control center QEL-51. Suitable labels width 15...250mm and length 10-350mm. Roll of labels max. diameter 300mm. Productivity up to 35m/min..

The labeler labels the front and back labels or wraps the label around the bottle. Suitable bottles diameter 85mm, height up to 375mm. Productivity up to 850 pdl/h, printer for printing date or serial number. In addition to electricity 230V, compressed air 6bar 8.2l/min is necessary for the operation of the device. Additional equipment: joints for special bottles, sensor for already labeled bottles, printer.

Semi-automatic and high-quality labeler from an Italian manufacturer. Places the first and back labels on the bottle (stickers alternating on one roll) and automatically adds the batch number and date to the label. Dimensions: 365 x 670 x 340; weight 25kg; productivity up to 600pdl/h. PS Make sure that the bottles used are straight, i.e. not with an irregular surface. If it has an irregular surface, then: 1 - do not apply any label around the bottle to the bottle, as it tends to create wrinkles and air bubbles 2 - preferably apply the label on the front and back (from one roll) in order to convey enough graphics and data required by law with the label. 3 - avoid plastic materials for labels, especially polypropylene, which is particularly sensitive to surface irregularities. 4 - we recommend using plain paper or, as an alternative, coated paper of a certain weight.

Automatic labeling machine that can be connected to a line - very accurate and durable. Made in Italy. A compact size labeler that applies one label to round bottles. Durable - well-fitting and high-quality materials are used; tested and designed for continuous operation. Practical - preset electronics. Productivity: 800pdl/h; Size: 1150x1000x1650mm; Weight: 150 kg; Electrical connection 0.9kw/220V; Suitable bottles with a diameter of 45-115mm and a height of 50-180mm; Additional equipment: Integrated printer: 3-line text or numbers 50x30mm.

Additional equipment for the Etiemme labeling machine - printer: 3-line text or numbers 50x30mm.

Semi-automatic and high-quality labeler from an Italian manufacturer. Places the first and back labels on the bottle (stickers on one roll alternately) and automatically adds the batch number or date to the label (print as an accessory). Dimensions: 380 x 740 x 300; weight 14.5 kg; productivity up to 600pdl/h. The following accessories are included with the device: 2'he label labeling, accessories for narrow labels, which prevent the label from shifting on the label roll. Max. label dimensions: width 180mm, length 200mm. PS Make sure that the bottles used are straight, i.e. not with an irregular surface. If it has an irregular surface, then: 1 - do not apply any label around the bottle to the bottle, as it tends to create wrinkles and air bubbles 2 - preferably apply the label on the front and back (from one roll) in order to convey enough graphics and data required by law with the label. 3 - avoid plastic materials for labels, especially polypropylene, which is particularly sensitive to surface irregularities. 4 - we recommend using plain paper or, as an alternative, coated paper of a certain weight.

Stamp for putting the date and/or serial number on the label. Compatible with FlexLabeller manual labelers. The size of one sign is 3-4mm.
