Kettle BROK 90l round 6kW

Boiler with indirect heating and bottom-mounted stirrer.Thanks to the indirect heating system, in which the heating medium is glycerine heated by electric heaters, it is characterized by high working culture and economy of use. Throughthis form of heating, direct contact between the heater and the cooked food is avoided, which excludes burning.Ideally suited for mixing and preparing vegetables, meat, soups, pet food, sauces, pomades, jams. The boiler has safety features:• Protection against starting the boiler with the flap open.• Protection when the flap is lifted, the boiler shuts down automatically. • Safety switch. The use of glycerine makes the boiler keep warm longer after heating up, it does not cool down rapidly - this allows more economical operation. Ergonomic design ensures operation of temperature settings, stirrer, lid and valve with one hand. Different types of stirrers available depending on the product to be mixed.Design: • made of AISI 304 stainless steel, cylindrical shape outside and inside, double-walled with glycerine filling without thermal insulation, • 1 1/4” faucet, stirrer, mobile on 3 swivel casters, including 1 with brake, power supply 400 V AC, 50 Hz • Available with a tap with a 2’’ faucet.

Made of stainless steel 1.4301 (AISI 304), grained surface, dihedral with glycerine filling, without heat insulation, 400Vpower supply, valve 1 1/4”, version on wheels.

The boiler is designed to safely, easily and automatically empty it of the products being prepared. The design of the boiler reduces the risk of injury to workers and increases process efficiency. Indirect heating is a safe and efficient way to prepare product.Made of 1.4301 stainless steel for long service and corrosion resistance. The flap located on two hinges is electrically lifted (push button), which ensures safety and convenience of use. The basket is lifted by an electric actuator. The design of the basket ensures easy and effective draining of the prepared products. (type of basket is matched to the product during the inquiry). Funnel design allows easy emptying of the boiler. Removable funnel. The boiler is equipped with a water refilling system. Valve 1 1/2’’ (optional 2’’). Digital control, wall-mounted control box. Heating medium: glycerine. Power of installed heaters 27 kW. Version on legs. Frame structure ensures stability of the boiler and trouble-free operation. Structure equipped with rails for forklift for simple transportation of the boiler. Boiler equipped with a bumper. Option: air mixing / different capacity. Maximum load 275 kg.

Made of stainless steel 1.4301 (AISI 304), ground surface, trihedral with glycerine filling, with heat insulation, digital temperture control, 400V power supply, pneumatic connection 6 bars, valve 2”, version on wheels (500 l on legs).

High-quality pasteurizer, cheese kettle. All products comply with EN 292-1, EN 292-2, EN 294, EN 349, EN 418, EN 1672-1, EN 60204-1 EU standards. An insulated water-jacketed cheese and yogurt stove, additionally equipped with a touch-sensitive control center and a planetary mixer. The entire work process is managed by configurable automation with a touch screen (heating, cooling, mixer, audio and visual signals at the end of the process). Technical data: Material stainless steel AISI304, Dimensions 107x127x170cm. Well-insulated 2-wall tank. Stainless steel heat exchanger with heating water connection ready. Easily removable mixer. Adjustable height legs, stainless measuring stick to determine the amount of liquid in the container. Fluid temperature sensor. Functionality: 1. Heating, cooling and mixing with fully automatic control. 2. Automatic mixer start/stop. 3. Audio and visual alarms at the end of the operation. Additional equipment: heating e.g. electric heating 24kw MilkCab 3100eur+km or 48kw 5600eur+km or with heat exchanger. cooling, removable stainless steel filter for storing cheese curds 250eur+km, removable stainless steel cutters with high resistance and elasticity 450eur+km, stick/fixer for blades 99eur+km, removable sidewall blade / it is placed on the side of the container and when the mixture falls on it, it causes waves and mixes the material in the container better 99eur+km, Kesk-Z mixer 450eur+km, Mixing shaft suitable for milk and yogurt process 350eur+km..

Kettles with a gas burner. The kettle is placed inside a large pot into which oil is added to ensure even heating. Complete with gas burner, oil, boiler with control center and mixing mixer. The kettle is ideal for making jams, equipped with a bottom oil bath and mixing paddles to ensure regular and even cooking of the ingredients and to prevent burning. The mixing speed can be adjusted from the control panel. The structure is mounted on a support frame, which allows for easy outflow and cleaning of raw materials from the machine. The delivery set includes a thermal oil and gas stove 8.5kw. Use: Fill the boiler with raw materials and add the supplied oil to the lower oil chamber of the boiler. Heat the boiler using the gas burner and occasionally checking the oil level in the boiler's black tub. Plug in the appliance and start the mixer. Allow to cook for the desired time and then remove the lid..

200l thick stainless steel tank/boiler with mixer and temperature indicator. Complete with: stainless steel outlet valve, analog thermometer with stainless steel guard, heavy metal reinforced lid, mixer with mixing paddles. Material: 18/10 stainless steel (AISI 304); Lid: stainless steel, 220V mixer with stainless steel blades, stainless steel handles, 1" stainless steel outlet valve. Dimensions: inner diameter: 720 mm, height: 800 mm, motor overall dimensions: 85 x 95 cm (h); base thickness: 1.5 mm; wall thickness: 1 mm; without insulation. Mixer 14 rpm..

The pasteurizer bath is suitable for heat treatment of raw materials in packaging. Bath size: 200l, heater power 12kw/400V (copper alloy), weight 130kg, automation IP65, bath material AISI 304 stainless steel. Maintains the set temperature. Dimensions 650x1350x900mm and internal dimensions 430x1000x 260-300 mm (WxLxH). Use distilled water and/or heating system fluids in the bath. Extras: Stainless steel heater..

Stainless boiling pot -pasteurizer with 300L tank and bottom mixer. Made in Poland. Technical data: Power 24kw/400V. Digital temperature control on the control center, auto start-stop, timer, timed work processes. Double-walled, glycerin-filled / Option to order a boiler on wheels or legs / Manufacturer's warranty 12 months
