INOX wine tank 380 l-3 valves

Hand pump to fill the tank floating lid seal..The size of the tank can vary up to max. +/-10%

Vaseline stainless steel container for sealing floating lids or lubricating seals. Vaseline oil is poured over juice or wine - the oil forms a layer on top of the drink that prevents air from coming into contact with the juice and protects the drink from fermentation. By using a floating lid with an oil seal, the apple juice also stays fresh for several months. The oil always remains on the surface of the juice, because it is lighter than the juice and thus does not mix with the juice. Vaseline oil is tasteless, odorless, colorless and has an unlimited shelf life. The oil is tasteless, odorless, transparent and has an unlimited shelf life..

Air lock for the tank for fermenting the product..

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, a water lock and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Stainless sealed container for storage or fermentation. Dimensions: D636mm, H 1470mm. Standard equipment: welded legs, bottom outlet - ball valve 1", side outlet - ball valve 1", sampling valve DN15, top cover Ø385mm, analog thermometer, level indicator Ø16 mm, 2 × inert gas fitting ½”.The size of the tank can vary up to max. +/-10%

Stainless steel conical bottom container with floating lid. Size: 1100L; Diameter: 953mm; Height: 1920mm; Chromed valves 1" (bottom), sampling valve 1/2" ; Stainless steel Aisi 304 - 18/10; Stainless steel legs with a height of 320 mm.The size of the tank can vary up to max. +/-10%

300L plastic closed cone container conforming to food standards. Well suited for fermentation and storage of products. The set includes: tank 300L; painted metal base frame (RAL3009); closable lid with air vent; added outlet 500mm above tank bottom for sampling with valve 1/2"; discharge pipe below. 11/2". Additional options: open from the top (without a hatch), open from the top and a wide low container, with a frame from the top... the possibility to attach a mixer and insert from the top through the hatch,.

container on stainless legs for fermentation and/or short-term storage of wine. The set includes: legs; conical base; bottom valve 1" (220mm from the plane); sampling valve 1/2"; upper valve 1/2", upper spring cover, floating cover. Dimensions: diameter 636mm and height 1320mm. Leg height 320mm..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, a water lock and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Sealable container with a stainless 8-degree cone base. Size: 1100L; Diameter: 953mm; Height: 1970mm; Chromed valves 1" (bottom), sampling valve 1/2" ; Stainless steel Aisi 304 - 18/10; Stainless legs height 320mm Welded legs, 2 x cooling jacket connection ½”, bottom outlet - valve 1”, side flow valve 1”, bottom oval door, top door Ø385 mm, sampling valve DN15, analog thermometer and with probe, level sensor Ø16mm..The size of the tank can vary up to max. +/-10%

Closed container on stainless steel legs with 2 hatches - upper and lower cleaning hatch. The set includes: legs; conical bottom 5%; thermometer; liquid level gauge; 2x air release valve; sampling valve 1/2"; bottom valve 1", top wing cap, bottom purge hatch..The size of the tank can vary up to max. +/-10%

Stainless steel conical bottom sealed container. Size: 10,000L; Diameter: 1595mm; Height: 5320mm. Standard equipment: welded legs, outlets - ball valves: bottom DN40 and side DN25, sampling valve DN15, oval cleaning door, top hatch Ø385 mm, analogue thermometer, level indicator Ø16 mm, 2 × inert gas fitting ½”, ladder support Extras: valves - DN, WG, gorolla, TC, Macon; lower valve DN50, cap / vent valve, lifting ears, inox nameplate, adjustable feet.The size of the tank can vary up to max. +/-10%

Container on stainless legs for short-term storage or fermentation of wine (additional fermentation kit required). The set includes: legs; conical base; only side valve 3/4", top spring cover, simple floating cover. Dimensions: diameter 636mm and height 1320mm. Leg height 320mm..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation. The set includes a floating cover, a hand pump, a seal, an air-water seal and an outer dust cover seal. Suitable seal 950mm.The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, a water lock and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, an air-water seal and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, an air-water seal and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation or airtight storage. The set includes a floating cover, a hand pump, a seal, an air-water seal and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

Tank accessories for fermentation. The set includes a floating cover, a hand pump, a seal, an air-water seal and an outer dust cover seal..The size of the tank can vary up to max. +/-10%

500l container on wheels with ready mixer connection on the side. The mixer is not included in the price. The container has a diameter of 796 mm and a height of 1700 mm. Additional options: moving with a forklift, mixer.The size of the tank can vary up to max. +/-10%

The 300-litre stainless steel tank is a professional-quality product designed for wine industry companies to store wine while meeting robustness requirements. Made of AISI 304 stainless steel, it ensures total preservation of the organoleptic characteristics of the contained product. Its 10° conical bottom with reinforcements facilitates ideal wine decantation, and the included stainless steel wine taster allows small quantities to be extracted for quality checks. The tank is equipped with a partial drain featuring a stainless steel valve and a 1" x ENO 30 plastic elbow, a full drain with a 1" x ENO 30 valve, and a 400 mm anti-retention top manhole cover, making it specialised equipment for the wine sector. With a 300-litre capacity, it is ideal for small and medium-sized businesses seeking efficiency and reliability. Characteristics: Material: stainless steel AISI 304. Capacity: 300 L. Internal finishes: mirror polished. External finishes: flamed with satin welds. Conical bottom: 10° with reinforcements. Total discharge: 1" x ENO 30 valve (3). Partial discharge: stainless steel valve and 1" x ENO 30 plastic elbow (1). Upper manhole cover: 400 mm, non-returnable. Conical roof: 10°. Feet: 3 stainless steel. Vent valve: double-acting plastic. Wine taster: stainless steel (2). CE safety standards compliant. Dimensions: Diameter: 640 mm (D1). Roof height: 300 mm (H4). Virola height: 1000 mm (H3). Foot height: 400 mm (H2). Total height: 1700 mm (H1). Thickness: Walls: 1 mm. Bottom: 1.5 mm.

Rust-free pre-fermentation container for raw materials, open on top and crushed on legs. The outlet height of the conical tank is 450mm and the opening is DN50mm. From the lower valve of the tank, the product can be discharged directly to the pump with the screw tank and pumped to the press Ps. The picture is illustrative..The size of the tank can vary up to max. +/-10%

Boiler / mixing tank stainless base with dimensions 720 x 720 x 260 h.

With the mixing container, you can adjust the taste of your juice, wine, etc. drink. Complete with a stainless steel mixer with mixing paddles, the speed of which is set to ensure a perfect mixing process, minimizing exposure to oxygen. The stainless steel tank is additionally complete with 2 valves D25mm and D20mm and an added washing head. Dimensions: ø63 cm + 20 cm valve; height 158cm, 220V motor 0.18 kW; Stainless steel mixing spoon as measuring stick, Check hatch with button. Mixer 14rpm or 28rpm (specify when ordering)..

Stainless conical container for fermentation under pressure, storage. Technical information: conical bottom 60º; Container diameter 565 mm, total height approx. 2220 mm. , stainless metal 2mm (EN 1.4301 (AISI 304) ; pressure 2.5bar. Standard equipment: a) pressure valve max. 2.5...3 bar b) thermometer c) rotating CIP washing head d) outlet DN40 from the bottom e) outlet from the center of the cone DN25 f) Hatch at the top Ø300mm. Additional equipment: a) Level sensor b) adjustable feet c) outlet valve d) drain valve e) lower cleaning hatch f) insulation.The size of the tank can vary up to max. +/-10%

Stainless tank size 100L with bottom tap, closed top (opening in the middle of the top with a cap). Diameter: 398mm, height 1130mm. stainless valve 3/4". Stainless steel Aisi 304..The size of the tank can vary up to max. +/-10%
