Heat exchanger Maxi 80 60-elements

The Maxi 80 heat exchanger is made of AISI 304 stainless steel (18/10). Complete with stainless steel interface F 1 "¼ and 3/4" M and 4 stainless steel hose connections with 20 mm 3/4 "F nut (as in the picture). Professional model suitable for transferring the temperature of one fluid to another fluid. Heat exchange is carried out by the stainless steel plates of the heat exchanger without the two fluids mixing. The device is removable and removable and the seals between the plates ensure perfect isolation. The fluids flow in the opposite direction and thanks to the wavy surface of the plate, it causes a high turbulence of the fluids flowing inside, improving the heat exchange. Complies with European Directive 97/23 / EC (PED). Advantages: high coefficient of heat exchange, LIQUIDS DO NOT MIX, FLEXIBLE (possibility of increasing the plates), DURABILITY thanks to the regeneration of plates and / or replacement of various components. TECHNICAL CHARACTERISTICS: CONNECTIONS 1 "1/4, MAXIMUM WORKING PRESSURE: 10 bar, Plate surface: 0.08 square meters, Plate liquid volume: 0.25L, WEIGHT OF ONE PLATE: 0.5 kg, WEIGHT: 50kg, Number of plates: 60 - capacity approx. 80kw CLEANING AND SANITIZING: The device must be cleaned immediately after use to prevent residues from drying and sticking to the walls and internal surfaces of the heat exchanger: first rinse with hot water and then use e.g. OXI or some other basic cleaning agent with warm water. Then rinse again with water. Store the heat exchanger in a clean and dry place. Disinfection is always carried out before the next use: circulate a solution of water and acid cleaner or OXI solution. Warning: Gloves, goggles and a mask are always recommended at this stage..
