Filter VIRGILIO 30 plate

Stainless filter housing on wheels with matching pump and bypass, which ensures that the pump can be used for other purposes as well. The housing is equipped with a 20-filter element input option, allowing to clean 700-1200l/h. Suitable filter elements 20 pcs with dimensions 20x20cm (at extra cost). The total area of the filters is 0.8m2. Size: 780x310 h530. Weight: 45 kg. We recommend buying suitable filter elements. Made by Grifo Italy..

10-element filter with pump and bypass in a stainless housing for the demanding small producer. Total filter surface 0.4m2; productivity 300-600l/h, pump hp0.5; dimensions 590x310xH530mm; weight 35kg Italian quality!.

A 10-element filter in a stainless housing for a demanding small producer. Suitable for filtering juice, wine, beer, oil, etc. Total filter surface 0.4m2; productivity 130-280l/h, pump enos 20, dimensions 600x330xH440mm; weight 13 kg. Italian quality!

A filter with 20 elements in a stainless housing for a demanding small producer. Suitable for filtering wine, juice, beer, oil, etc. Total filter surface 0.8m2; productivity 600-900l/h, dimensions 600x500xH750mm; weight 36 kg. Italian quality! Accessories: self-priming pump, filter elements..

Filter with pump. Possibility to reduce the number of tiles by 2 up to 4 tiles. Easy to move using the handle. A drip tray under the filters. You can also use the pump separately, for example, for different feed liquids such as wine, beer, juice, etc. Standard model with NBR seal up to +60°C. Hose connections: 20mm; motor: 0.5 hp, 230 volts, 50 Hz, 2850 rpm. 18-plate 20 x 20 cm; productivity 550-800 liters per hour. Hoses are not included!.

Stainless filter housing on wheels with matching pump and bypass, which ensures that the pump can be used for other purposes as well. The housing is equipped with a 30-filter element input option, allowing to clean 1000-1800l/h. Suitable filter elements 30 pcs with dimensions 20x20cm (at extra cost). The total area of the filters is 1.2m2. Size: 800x310 h530. Weight: 55 kg. We recommend buying suitable filter elements. Made by Grifo Italy. Extras: Intermediate plate, which allows the use of 2 different filter elements in one filtration cycle..

Professional and high-capacity filter unit with 40 filter plates. Suitable for filtering wines, sparkling wines, oils, low alcohol liqueurs and herbal drugs. Inlet and outlet control valves with a visual inspection spacer to check the output product. In addition, it is equipped with taps for air ventilation and the possibility to take samples of the processed product. Technical description: dimensions 175x63x122cm, weight 370 kg, plates 40x40cm, production capacity per hour (wine) 4000l, (oil) 400l, pressure 3 bar.

SPECIAL PRICE FOR DEMO MODEL ONLY!Professional and high-capacity filter unit with filter plates 40x40cm 20 pcs. Suitable for filtering wines, sparkling wines, oils, low alcohol liqueurs and herbal drugs. Inlet and outlet control valves with a visual inspection spacer to check the output product. In addition, it is equipped with taps for air ventilation and the possibility to take samples of the processed product. Technical description: dimensions 100x60x900cm, weight 250 kg, plates 40x40cm, production capacity per hour (wine) 2000l, (oil) 350l, pressure 3 bar.

Designed specifically to meet the needs of small and medium-sized businesses. Made of stainless steel, practical and safe. Depending on the density of the cardboard filter, it is possible to filter white and red wines, sparkling wines, vinegars, herbal products, liqueurs, etc. and even sterilize them. The filtration series consists of devices with a filtration capacity of 100 to 5,000 liters of wine per hour. Centrifugal type stainless steel electric pump is installed for all applications except olive oil filtration which requires single screw or nitrile impeller type pumps. The 20 x 20 cm support plates are made of food grade plastic or, if desired, NORIL, can be sterilized at 120 °C. The machine is mounted on an AISI 304 stainless steel trolley equipped with 4 wheels (2 with brakes) to move the filter easily. Standard stainless steel taps.Features: Filtering surface: 1.2 m2, dimensions of the elements used: 20 x 20 cm (cardboard filters must be purchased separately), Wine processing: 1000 ÷ 1800 l/h, Dimensions: 770*300*560h, Weight: 47 kg, Hose reduction 20 for a hose with an internal diameter of mm. Optional accessory: double filter plate (sold separately)

Tandem Professional filter housing, with which it is possible to filter wine, liqueurs, syrups and fruit juices, by simply changing the filter cartridges and getting a result at a professional level. The filter elements are washable and reusable, available in different materials and with different levels of filtration. A 3-filter element fits in the housing. It is possible to use pressurized filtration or with the Enolmaster bottler. Technical description: Overall dimensions: 32 x 30 x 28 h cm, elements sold separately, hose connection for 25mm inner diameter pipe..

Stainless filter with 1.2 mm openings, suitable for use in many purposes. When pre-filtering the pressed juice, place the filter in the container and fasten it. Then direct the juice to the filter, where the larger sediment remains in the filter and the juice flows through the filter into the container. Extraction of juice from crushed juice residues. Place the filter in the ee-crushed raw material container. The juice then seeps into the filter, where it is pumped out. In this way, the work of pressing is faster, since a part of the juice has already been removed. Filter dimensions: height 100cm and diameter 15cm. Perforated filter 2mmx3.5mm.

High-quality stainless steel filter with 1 element. The stainless mesh filter element has a density of 0.3 mm (300 microns). The filter is not suitable for removing suspended matter from the liquid, e.g. yeasts and various suspended particles. Special order filter elements available from 0.05mm/50mik to 8mm/8000mik and larger filters up to DN150. Ask for more SMS connections..

High-quality stainless steel filter with 2 elements. The stainless mesh filter elements have a density of 0.1 mm (100 microns). The filter is suitable for pre-filtering juice or sediment. The filter is not suitable for removing suspended matter from the liquid, e.g. yeasts and various suspended particles. Includes 2 filter elements. Special order filter elements available from 0.05mm/50mik to 8mm/8000mik and larger filters up to DN150..

Micro-filter Housing 30". These special filters consist of a shell made of AISI 316 stainless steel 30", inside which a special cartridge is placed, which allows thorough cleaning, cold sterilization or polishing of wine, beer and fruit juices. All parts which are in contact with the liquid are made of stainless steel and completely removable for easy cleaning. The membrane filter has a pore size of 0.1 - 10 µm which carry out micro filtration. Material: AISI 316 30". Flow rate: 1000 L/h. Pore size: 0.1 - 10 µm. Apparatus complying with CE safety standards. Cartridge not included.
