Dosator Telm 5-250ml, 50L with a mixture container

Compact dispenser with a 50l mixing container, which has a mixing mixer inside. The device must be placed on top of an existing table. The structure of the dispenser is completely made of stainless steel AISI 304. The base is equipped with all the controls for the suction and dispensing devices, an emergency button, an air inlet and a lubricant reducer filter. The container is placed on a support plate with adjustable height and depth to enable dosing into containers with the following dimensions: D.min 15mm - D.max 120mm; H.min 10mm - H.max 210mm. The start of the dosing cycle is given by the operator using the 2M foot pedal. Rinse cycle: the switch activates the repetition of strokes. The machine continues to dispense doses until the button is turned off: this feature is useful for rinsing the machine after filling. The machine works with 6 bar compressed air. DOSER 5-250ML The volume dispenser is completely made of stainless steel AISI 316. The amount of dosing can be adjusted between 5ml and 250ml using the hand wheel behind the dispenser. All sealants used meet nutrient exposure standards. The dispenser is equipped with Tri Clamp connections to facilitate disassembly and cleaning of all parts in contact with the product. 3D FLAP VALVE Three-way conical rotary valve Mignon, completely made of stainless steel. Conical shutter made of anti-friction and FDA-approved plastic material, suitable for contact with the product being handled at temperatures up to 50°C. All Tri Clamp connections to facilitate disassembly and cleaning of all parts in contact with the product. Insertion 10x20mm is suitable for passing dense products with small pieces. STANDARD OUTPUT NOZZLE 1 "standard nozzle, made of stainless steel. Available in different formats according to the dimensions of the container. CONICAL CONTAINER WITH MIXER STRIP Conical 50l container with mixer (horizontal in the picture) is included in the set. Made entirely of stainless steel and attached to the general frame. The lid of the container is made of transparent polycarbonate. and consists of two parts - one part closed and the other openable.The hopper is equipped with a safety switch.Stainless steel mixing paddles ensure uniform mixing of the product and prevent lumps from settling.Electrical cabinet with start/stop device and potentiometer to adjust the speed of the mixer..
