DOS EPH19n4

Easy filling: Our automatic weighing filling packaging machine processes particles up to Φ<10mm, and that's not all! It effortlessly bottles everything from spice powders to tea leaves to grains. Precise Filling: With its built-in two-stage vibration motor, our particle filling machine ensures an accuracy of ±1g. Easily bottle anything from 1g to 100g. Compared to single vibration motors, our double vibration motor ensures better discharge and avoids residue inside. Smart Control: Take control effortlessly! The automatic powder filling machine has a smart control panel that allows you to easily adjust filling weights and speeds for different materials. It is multifunctional and very easy to use. Sensitive Sensing: No more manual effort! The outlet port of our powder packaging machine has an intelligent infrared sensor function that automatically detects when to dispense without the need for switches. Robustly built for long-lasting use: Our powder filling machine is made entirely of stainless steel and has important components (hopper/vibration trough/weighing hopper/discharge port) made of food-grade 304 material. It ensures reliable performance and safety with every filling.

.

The high-quality CE-certified DOSELITE dispenser made in Italy allows dispensing volumes of 5-380ml. It is possible to dose oil and various liquids. KIT: adjustable dosing flask 5-380ml + 3D valve (viscous liquid) + stainless bottling nozzle Ø20/25mm and raw material funnel are added to the product price. DESCRIPTION OF THE WORKING PROCESS: Connect the hose and place the liquid (if it is very viscous, we recommend using a funnel that is filled with the raw material), when you press the button, the device creates a negative pressure and sucks the liquid into the flask, and then the liquid is forced out of the measuring flask through the outlet nozzle with the help of compressed air. A hand crank is installed on the rear side of the product, which determines the exact volume of the dosing or piston. All seals are made of materials that comply with food standards, and the rest of the material that comes into contact with the substance to be bottled is made of stainless steel. When cleaning the bottling device, it is not necessary to have special tools - everything opens easily and quickly. The flow and speed of the substance to be bottled can be adjusted with 2 air pressure regulators. Warranty 12 months. The working process of the product requires a 6bar compressed air compressor, preferably with a 50-100L hydrophore, which is not included in the product price..

Crown cap and ice cap removal, hand dispenser and bottler all in one device. For small volume production..

Semi-automatic monobloc for filling and sealing tare (cans, bottles). Cap and bottle filling and closing device for screw caps. The semi-automatic air-operated machine is suitable for bottling liquid or semi-liquid products into cans or bottles. All parts that come into contact with the product are made of AISI 316L stainless steel and complete with seals that comply with food standards. The corkscrew has an adjustable torque and a pneumatic motor. Productivity up to 400 cans/h for 350ml cans. Volume cylinders are available for bottling tare in the following sizes: 5 to 250 ml; 5 to 380 ml; 20 to 680 ml; 50 to 1500 ml This device can fill viscous products containing soft solid particles or fibers and is also suitable for hot filling (95°C). Technical characteristics: The main frame of the machine is made of stainless steel AISI 304; All the supports and the shaft of the machine, which may come into contact with the raw material, are made of stainless steel AISI 304; manual individual arrangement of the jar; Volumetric filling module consisting of: 1 part AISI 316 L stainless steel; 1 set with gaskets; 1 three-way rotary valve; 1 pneumatic two-way shut-off valve without shut-off nozzle; Food grade flexible hose; A single-ended capper consisting of: 1 pneumatic motor; 1 stainless steel nozzle of one size; Manual height adjustment of the machine. Air consumption ~ 250 Nl / min compressed air 2 - 6 bar.

Dispenser made in Italy, suitable for bottling liquid or viscous raw materials. The device with easy-to-open and close clamps is easy to maintain and clean. Dispensers: 1-18ml; 1-38ml, 2-48ml, 2-100ml, 5-250ml, 5-385ml, 20-700ml, 50-1500ml, 50-2200ml, 200-5600ml. price calculated: dispenser 5-385ml, container 15l, viscous liquid temp. max. +50C.
