Discorking-Dosage unit Alpha 150pdl/H

semi-automatic 3in1 device for the shampoo method disc corker-dispenser and liquid level control bottler. Made in Italy. Made of stainless steel. The device can be used to remove the pre-cooled cap from the bottle neck + foam removal with compressed air (manometer, compressed air valve) + bottle neck slot with liquid setting + manually controlled 3T valve with liquid dispenser. Productivity 150pd/h (0.75L) / bottles D 70-114mm and H 245-380mm / weight 75kg / size: 75x60x160 / compressed air 0.5/2bar.

Manually removing crown caps and ice caps from shampoo bottles..

Crown cap and ice cap removal, hand dispenser and bottler all in one device. For small volume production..

Crown cap remover..

Crown cap remover for 29mm corwn caps.

Doselite bottling nozzle for viscous substance..

Automatic valve removal, bottling and valve installation. Possibility of vertical bags (pouch-up) min. 1 l. Productivity 3l 380pcs, 5l 240pcs/h, 10l 210pcs and 20l 140pcs. Dimensions 800x1000x1500mm, weight 110kg. Control with touch screen PLC SIEMENS, multi-language and multi-program, Induction flow meter, Vacuum system and nitrogen injection, Automatic opening / closing of bags in Vitop standard set, Volumetric pump with self-cleaning rubber wheel impeller 900 rpm with bypass and total drain valve, Vacuum-proof filling system, Possibility to fill flexible bags or bag ( higher type) since then, min. bottling with 1L capacity, 4-wheel stainless steel frame, Inox fitting for CIP cleaning, automatic cleaning program, Safety guard, Adjustable stainless support when filling boxes. Max. bottling temperature +90C. Bottling capacity up to 4500l/h. Induction meter accuracy class 0.2% and disinfection up to +120C. It is possible to save 10 different programs when bottling pre-calibrated liquids, which means that once a liquid/program has already been calibrated and saved, it is not necessary to perform a new calibration, but to retrieve the corresponding program from the memory Extras: electronic bottling speed control, intermediate tank with automation, compressed air compressor, automatic additional tool for special bag for caps, oil bottling accessories, filter 10" or 30", air filter..

Semi-automatic shampoo bottle capper + wire tie. Made in Italy. Made of stainless steel - device on wheels. Pneumatic bottle lifter for cap pressing and wire binding at the push of a button. Manual wire installation and hand crank wire tie. Productivity 500pd/h / suitable bottle sizes: 0.3-1.5L / weight 180kg / height 180cm, width 90cm, depth 65cm / 0.75kw 380V.

High-quality and semi-automatic bottler for juice storage bags. Productivity 420l/h, dimensions 1030 x 1650 x 800 mm, weight 140kg.

Compact stainless steel mobo block from an Italian manufacturer. The standard device bottles and caps bottles in the size of e.g. with a diameter of 75mm (75cl). Caps D22-28mm with a height of up to 50mm. productivity up to 800pdl/h (75cl). The device is also suitable for bottling and capping oil. Additional equipment: conveyor belts, vacuum (accelerates productivity/bottling process)..
